XVR Off-Road Pod

17 years of engineering, research and design. This is it. Perfect for the pure off-road enthusiast.

No set up. No canvas. Lightweight. Easy. Nimble but luxurious.

Dimensions

Internal Length: 3547mm

Overall Length: 5223mm

Overall Width: 1973mm (without awnings)

Storage Height: 2190mm

Weights

Tare Weight: 1580kg

ATM: 2250kg

Ball Weight: 170kg

Fluid Capacity

Fresh Water: 215L

Diesel Tank: 12L

Specifications

645W solar array

480AH lithium batteries

REDARC BMS with RedVision

3000W pure sine wave inverter

Electronic air suspension with multi ride height

Electronic dust suppression system

Awning

Integrated 100kg rated roof rack

Diesel hot water & heater

External shower with ensuite awning & portable toilet

Rear outdoor kitchen featuring dual induction cooktop, sink & two stainless steel pantry drawers

23L microwave

130L upright refrigerator

Dual entry doors each side with steps

Queen-sized inner spring mattress with additional mattress (3 berth) /storage area

190L slide out under bed storage drawer

Floor Plan
Showcase Video

DISCLAIMER: Mountain Trail RV and its authorised dealers, retains the right to change designs, dimensions, weights, fittings, finishes, options and specifications without notice. Fittings and finishes are subject to availability and supplier discretion.

XVR
Features.

XRV Off-Road Pod: Your Lightweight Off-Road Camper

Dimensions & Weights.

670kg payload.

With a tare weight of 1580kg and ATM 2250kg, the XVR has an impressive load capacity that includes a 100kg rated roof rack as standard.

Your tow vehicle choice is endless.

With a height of 2190mm, garaging the XVR is easy.

Compact Smart
Design.

We’ve designed the XVR with a focus on functionality. Every inch has been cleverly engineered to ensure you get the most out of your XVR.

Dual entry doors on each side grant easy access. Queen-sized bed and under bed storage drawer.

Rear-Mounted Outdoor Kitchen.

Designed for easy access, the rear outdoor kitchen is located behind a rear lift-up door. Featuring bench space for food preparation, sink, dual induction stove and a 130L upright fridge. Dual stainless steel pantry drawers with sliding lids offer storage and food preparation for comfortable, convenient and easy cooking.

Off-Road Technology.

With MTRV-designed independent trailing air bag swing arm suspension, 12 inch electric brakes and DO35 coupling, you’ll be ready for anything. The multi-ride height suspension gives you quick leveling at the touch of a button.

Full Electric Pod.

The XVR has a total electric system. 12 volt USB connectivity and 240 volt sockets throughout are all managed by the REDARC Redvision Total Vehicle Management System.

European Composite Wall Panels.

We’ve sourced the best materials in the world to ensure our off-road caravans have the highest insulation properties available. Precision cut in our factory from whole panels utilising CNC (computer numerically controlled) machinery.

Dust Suppression.

With positive pressure technology in your XVR, you have the peace of mind that dust will be deterred from entering your off-road pod.

No more pulling up to find a dust filled pod.

Luxury & Comfort.

After a long day touring there is nothing better than retreating to the luxury of the XVR. Easy to set up, you will be relaxing in stunning locations in no time.

Sleep comfortably on the full size queen mattress knowing that external noise will be reduced by the highly rated insulation properties of the outer shell .

Solar Power.

Enough solar charging and power for self sufficiency. Roof mounted 645 watt solar system, 480 amp lithium batteries and a 3000-watt inverter enable you to use 240 volt appliances including the optional under bunk mounted air-conditioning.

Front Storage Box.

The XVR features our front storage box, designed to give protection to the pod from stones whilst on the road. Coated and sealed with rubberised paint, it also includes a vented box dual 20L fuel holders, 9kg gas bottle holder and a centre section sealed with marine grade carpet.

External Shower.

The XVR has been cleverly designed to feature a shower awning and external combined ensuite. Featuring a mixer tap shower head, diesel powered hot water and a portable toilet, it can be set up ready for use in minutes.

Go Further, Explore More: Lightweight & Off-Road Ready

XVR Pod Showcase

Want a comprehensive video that walks you through specs, features and construction of our Luxury Offroad LXV 4.7?

Look no further…

.

Brochure & Pricing Download

Enter your details into the form above to receive a link to an XVR brochure in your email.

If you have any questions, please call us on (02)6040 4488
